Blind Flanges

ANSI B16.5 Stainless Steel BLRF Flanges, Inconel Blind Flanges, ANSI B16.47 Carbon Steel Blind Flanges Supplier

Alloy Steel Blind Flanges, Duplex Steel BLRF Flanges, Monel BLRF Flanges, Nickel Alloy Blind Plate Flanges Exporter In India.

Sanghvi Overseas is one of the prime manufacturers of Blind Flanges that are being sourced by using high quality of raw material and makes sure to provide durability of highest quality of industry standard products. Our Stainless Steel Blind Flanges are being used to uniform off the ends of piping, pressure vessel and valves opening. These Carbon Steel Blind Flanges are supplied through appropriate test certificates of standardized finished products and raw materials. Our Alloy Steel Blind Flanges can be easily handle at elevated stress from inner pressure, for the reason that the utmost stresses in these flange are bending stresses at the center. The main benefit of Duplex Steel Blind Flanges is that the lesser time required to spent on making sure the precision of the cut pipe Meanwhile, these Super Duplex Steel Blind Flanges can further be customized in terms of sizes and thicknesses as per specific requirements given by our esteemed clients. We offer these High Nickel Alloy Blind Flanges in market leading prices.



Also check our ASTM A182 Stainless Steel Flanges

Stainless Steel Blind Flanges
Stainless Steel Blind Flanges
Carbon Steel Blind Flanges
Carbon Steel Blind Flanges

Blind Flanges Specification :

Standards :ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings

Size : 1/2″ (15 NB) to 48″ (1200NB)

Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.

Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673

BS : BS4504 , BS4504, BS1560, BS10


Blind Flanges Material & Grades :

Stainless Steel Blind Flanges : ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L

Alloy Steel Blind Flanges : ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91

Duplex & Super Duplex Steel Blind Flanges : ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61, 2205 (UNS No. S31803), 2507 (UNS No. S32750)

Carbon Steel Blind Flanges : ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F70

Copper Alloy Steel Blind Flanges : UNS No. C 10100, 10200, 10300, 10800, 12000, 12200, 70600, 71500, UNS No. C 70600 (Cu -Ni- 90/10), C 71500 (Cu -Ni- 70/30)

Nickel Alloy Blind Flanges : Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II)
